Starting with the first-generation NanoBridge, Ubiquiti Networks pioneered the all-in-one design for an airMAX product functioning as a CPE (Customer Premises Equipment). Now Ubiquiti Networks launches the latest generation of CPE, the PowerBeam.

Improved Noise Immunity The PowerBeam directs RF energy in a tighter beamwidth. With the focus in one direction, the PowerBeam blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.

Integrated Design The PowerBeam models are available in two form factors:

• All-in-One Design The Ubiquiti Research and Development team combined the radio and antenna to create a more efficient and compact CPE. The PowerBeam gets maximum gain out of the smallest footprint.
• Dish Reflector Design Ubiquiti's InnerFeed technology integrates the radio into the feedhorn of an antenna, so there is no need for a cable. This improves performance because it eliminates cable losses. Providing increased performance from its faster processor and innovative mechanical design at a low cost, the PowerBeam is extremely versatile and cost-effective to deploy

Operating Frequency: 5150 - 5875 MHz
Gain: 25dBi
Built-In Mechanical Downtilt: +20° _ -10°
Output Power: 26dBm
Polarization: Dual Linear
Max. VSWR: 2:1
Channel Sizes: 5/8/10/20/30/40 MHz
Power Supply: 24V, 0.5A GigE PoE

Dimensions: 420 x 420 x 275 mm
Weight: 1.753 kg
Operating Temperature: -40°C +70°C

Processor Specs: Atheros MIPS 74KC, 560MHz
Operating Memory: 64MB DDR2
Flash Memory: 8MB
Networking Interface: 10/100/1000 Ethernet Port
