• Crystal-Clear 4MP Imaging: Delivers high-resolution video at 2560 × 1440 for detailed surveillance.

• Human & Vehicle Detection: Advanced analytics help reduce false alarms and improve threat accuracy.

• Smart Hybrid Light: Automatically switches between IR and white light with a range up to 30 meters.

• Built-in Microphone: Enables real-time audio monitoring for enhanced security awareness.

• Efficient H.265+ Compression: Reduces storage and bandwidth usage without compromising video quality.

• Optional Onboard Storage: Supports microSD cards up to 512GB (select models only).

• Rugged Design: IP67-rated water and dust resistance, and IK08-rated vandal resistance for harsh environments.

📸 Camera Specifications

• Image Sensor: 1/3″ Progressive Scan CMOS

• Max Resolution: 2560 × 1440 (4MP)

• Min Illumination:

  • Color: 0.005 Lux @ (F1.6, AGC ON)

  • B/W: 0 Lux with IR

• Day/Night: IR cut filter

• WDR: 120 dB

• SNR: ≥ 52 dB

• Image Enhancements: BLC, HLC, 3D DNR

• Privacy Masking: Up to 4 polygonal areas

🔭 Lens Options

• Aperture: F1.6

• Lens Mount: M12

• Angle Adjustment: Pan: 0°–355°, Tilt: 0°–75°, Rotate: 0°–355°

🌙 Illumination

• Smart Hybrid Light: IR + White Light

• Range: Up to 30 meters

• IR Wavelength: 850 nm

🎥 Video Performance

• Main Stream:

  • 50Hz: 20fps @ 2560×1440, 25fps @ 1920×1080 / 1280×720

  • 60Hz: 20fps @ 2560×1440, 24fps @ 1920×1080 / 1280×720

• Sub-Stream:

  • 50Hz/60Hz: 25/24fps @ 1280×720 / 640×480 / 640×360

• Compression: H.265+, H.265, H.264+, H.264, MJPEG

• Bitrate Control: CBR / VBR (32 Kbps to 8 Mbps)

• ROI: 1 fixed region

🎧 Audio

• Built-in Microphone: Yes (Mono)

• Compression: G.711u/a, G.722.1, G.726, MP2L2, PCM, AAC-LC

• Audio Bitrate: 16 – 160 Kbps

• Noise Filtering: Yes

• Sampling Rates: 8 kHz / 16 kHz

🌐 Network & Security

• Network Protocols: TCP/IP, DHCP, HTTP, RTSP, FTP, NTP, IPv6, and more

• API: ONVIF (Profile S, G, T), ISAPI, SDK

• Max Users: 32 (admin/operator/user roles)

• Security: Password protection, watermark, WSSE, digest auth, audit logs

• Client Support: iVMS-4200, Hik-Connect

• Browser Support: IE10/11 (live view plugin), Chrome/Firefox (local service)

💾 Storage & Interfaces

• Ethernet: 1x RJ45 10/100M self-adaptive port

• Onboard Storage: Up to 512GB microSD (on “-F” models only)

• Reset Key: Available on “-F” models

• Audio & Alarm: Motion detection, human/vehicle detection, video tamper

• Linkage Actions: Email alerts, FTP upload, snapshot, recording

⚙️ General Specifications

• Power Supply:

  • 12V DC ±25% (Max 6W),

  • PoE IEEE 802.3af (Max 7.5W)

• Material: Metal + Plastic

• Dimensions: Ø121.4 mm × 97.7 mm

• Weight: Approx. 550 g (800 g with packaging)

• Operating Temp: -30°C to 60°C (-22°F to 140°F)

• Humidity: ≤95% RH (non-condensing)

• Protection Ratings: IP67 (weatherproof), IK08 (vandal resistant)

📜 Certifications

• EMC: FCC, CE-EMC, RCM, IC

• Safety: UL, CB, BIS

• Environment: RoHS, WEEE, REACH

•
