• 4MP Ultra HD Resolution: Capture sharp and detailed footage at 2560 × 1440 resolution.

• 24/7 Full-Color Imaging: Powered by F1.0 super-aperture lens and smart hybrid light (IR + white light).

• Smart Hybrid Light Technology: Automatically switches between infrared and visible light for enhanced clarity up to 30 meters.

• AI-Powered Detection: Supports accurate person and vehicle detection with fewer false alerts.

• Built-In Two-Way Audio & Strobe Alarm: Includes microphone, speaker, and flashing light for active deterrence.

• Onboard Storage: Supports microSD cards up to 512 GB for edge recording.

• H.265+ Compression: Reduces storage and bandwidth while maintaining video quality.

• Rugged & Weatherproof: IP67-rated for outdoor use.

📸 Camera Specifications

• Image Sensor: 1/3″ Progressive Scan CMOS

• Max. Resolution: 2560 × 1440 (4MP)

• Min. Illumination:

  • Color: 0.001 Lux @ (F1.0, AGC ON)

  • 0 Lux with built-in light

• Shutter Speed: 1/3 s to 1/100,000 s

• Day/Night: IR cut filter

• WDR: 120 dB

• SNR: ≥ 52 dB

• Image Enhancements: BLC, HLC, 3D DNR

• Privacy Masking: Up to 4 polygonal zones

• Image Adjustments: Saturation, brightness, contrast, sharpness, gain, white balance

🔭 Lens Options

• Aperture: F1.0

• Lens Mount: M12

• Adjustment Range: Pan: 0°–355°, Tilt: 0°–90°, Rotate: 0°–355°

🌙 Illumination

• Type: IR + White Light

• Range: Up to 30 meters

• IR Wavelength: 850 nm

• Smart Supplement Light: Yes

• Flashing Light Options:

  • SRB Model: Red & Blue Light

  • SL Model: White Light

🎥 Video

• Main Stream:

  • 2560×1440 @ 20fps

  • 1920×1080 / 1280×720 @ 25/24fps

• Sub-Stream:

  • 1280×720 / 640×480 / 640×360 @ 24–25fps

• Video Compression: H.265+/H.265/H.264+/H.264/MJPEG

• Bitrate: 32 Kbps – 8 Mbps

• Bitrate Control: CBR / VBR

• SVC Support: Yes (H.264, H.265)

• ROI: 1 region

🎧 Audio & Alarm

• Built-in Microphone & Speaker:

  • Max. Speaker Output: 1.5 W

  • Max SPL @ 10 cm: 98 dB

• Audio Type: Mono

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC

• Audio Bitrate: 16 – 160 Kbps

• Noise Filtering: Yes

• Strobe & Audio Alarm: Triggered by motion or events

🌐 Network & Storage

• Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, FTP, IPv4/IPv6, UPnP, SMTP, IGMP

• API Support: ONVIF (Profiles S, G, T), ISAPI, SDK

• Max Users: 32 (Admin, Operator, User)

• Security: Password protection, watermark, MAC host authentication, WSSE, security audit log

• Client Software: iVMS-4200, Hik-Connect

• Browser Compatibility: IE10/11 (plug-in), Chrome, Firefox, Edge

💾 Storage & Interface

• Ethernet: 1 × RJ45 10/100 Mbps

• Onboard Storage: microSD/microSDHC/microSDXC, up to 512 GB

• Reset Button: Yes

⚙️ General Specifications

• Power Supply:

  • 12 VDC ±25%, Max 7.2 W

  • PoE (802.3af Class 3), Max 8.7 W

• Material:

  • Front Cover: Metal

  • Body & Bracket: Plastic

• Dimensions: 179 × 69.1 × 67.4 mm (7.05″ × 2.72″ × 2.65″)

• Weight: 320 g (540 g with packaging)

• Operating Temp: -30°C to 60°C (-22°F to 140°F)

• Humidity: ≤ 95% RH (non-condensing)

• Languages: English, Ukrainian

📜 Certifications

• EMC: CE-EMC, RCM, ICES

• Safety: CB, CE-LVD, BIS

• Environmental: RoHS, WEEE, REACH

• Protection: IP67 Rated (Weatherproof)

•
