• 6 MP High-Resolution Imaging for crystal-clear detail

• ColorVu Technology with Smart Hybrid Light for full-color images in low light, up to 30 m range

• Human & Vehicle Detection with intelligent alerts

• Efficient H.265+ Compression saves bandwidth and storage

• Built-in Microphone for real-time audio monitoring

• On-board Storage up to 512 GB (microSD card, optional)

• Weatherproof Design with IP67 protection for outdoor durability

Specifications

Camera

• Image Sensor: 1/2.4″ Progressive Scan CMOS

• Max Resolution: 3200 × 1800

• Min Illumination: Color 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light

• Shutter Speed: 1/3 s to 1/100,000 s

• Lens: Fixed 2.8 mm (115° HFOV) or 4 mm (94° HFOV), F1.0 aperture, M12 mount

• Angle Adjustment: Pan 0°–360°, Tilt 0°–90°, Rotate 0°–360°

Illumination

• Smart Hybrid Light: IR & White Light up to 30 m

• IR Wavelength: 850 nm

Video

• Main Stream: Up to 20 fps @ 3200 × 1800

• Sub-Stream: Up to 20 fps @ 1280 × 720

• Compression: H.265+/H.265/H.264+/H.264, MJPEG

• Bitrate: 32 Kbps to 16 Mbps

• WDR: 120 dB Wide Dynamic Range

• Enhancements: BLC, HLC, 3D DNR

• ROI: 1 fixed region

Audio

• Built-in Microphone: Yes (mono)

• Compression: G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC

• Noise Filtering: Supported

Network

• Protocols: IPv4, IPv6, TCP/IP, DHCP, HTTP, RTSP, FTP, SMTP, etc.

• Simultaneous Live View: Up to 6 channels

• User Access: Up to 32 users (admin/operator/user)

• Security: Password protection, watermark, MAC authentication, audit log

• Client Software: iVMS-4200, Hik-Connect

• Web Browser: IE10/11, Chrome, Firefox, Edge

Interface

• Ethernet: 1 × RJ45 10/100 Mbps

• Storage: MicroSD/SDHC/SDXC card, up to 512 GB (optional)

Events

• Basic Events: Motion detection, tampering, exceptions

• Linkage: FTP upload, email, snapshot, recording, alarm notification

General

• Power: 12 VDC ±25% (6.6 W), PoE (802.3af Class 3, 8 W max)

• Material: Front cover metal, body & bracket plastic

• Dimensions: 69.8 × 67.9 × 172.9 mm

• Weight: Approx. 550 g (800 g with package)

• Operating Temp: –30 °C to 60 °C (–22 °F to 140 °F), ≤95% RH

• Protection: IP67 weatherproof

Certifications

• EMC: CE-EMC, IC, RCM

• Safety: CB, CE-LVD, BIS

• Environment: CE-RoHS, WEEE, REACH

•
