• 6MP High-Definition Video (3200 × 1800) for detailed surveillance.

• Smart Hybrid Lighting: Switches between IR and white light with up to 30m coverage.

• AI Detection: Human and vehicle classification reduces false alarms.

• IP67 Weatherproof: Designed for outdoor environments.

• Efficient Storage: H.265+ compression reduces bandwidth and storage usage.

• Onboard Storage: Supports up to 256GB microSD (model-dependent).

• Built-In Microphone: Captures audio for added situational awareness.

🔍 Technical Specifications

📸 Camera & Optics

• Sensor: 1/2.4″ Progressive Scan CMOS

• Max Resolution: 3200 × 1800 (6MP)

• Min Illumination:

  • Color: 0.005 Lux @ F1.6 (AGC ON)

  • 0 Lux with IR

• Lens: Fixed (2.8mm or 4mm)

• FOV (2.8mm): 105° H / 55° V / 127° D

• FOV (4mm): 78° H / 38° V / 96° D

• Aperture: F1.6

• Angle Adjustment: Pan 0–360°, Tilt 0–90°, Rotate 0–360°

• DORI (2.8mm): Detect 76m, Observe 30m, Recognize 15m, Identify 7m

• DORI (4mm): Detect 115m, Observe 45m, Recognize 23m, Identify 11m

🌙 Illumination

• Lighting: Smart Hybrid Light (IR + White Light)

• IR Range: Up to 30m

• White Light Range: Up to 20m

• IR Wavelength: 850nm

🎥 Video

• Main Stream:

  • 20fps @ 3200×1800, 2688×1520, 1920×1080, 1280×720

• Sub Stream:

  • 20fps @ 1280×720 / 640×480 / 640×360

• Compression: H.265+/H.265/H.264+/H.264/MJPEG

• Bitrate: 32 Kbps to 16 Mbps | CBR/VBR

• ROI: 1 Region

• WDR: 120 dB

• SNR: ≥ 52 dB

🎧 Audio

• Type: Mono

• Microphone: Built-in

• Noise Filtering: Yes

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC

• Bitrate: 16 – 160 Kbps

• Sampling Rate: 8 / 16 kHz

🌐 Network & Smart Features

• Protocols: TCP/IP, DHCP, HTTP, RTSP, FTP, NTP, QoS, IPv6, SMTP, and more

• API Support: ONVIF (S, G, T), ISAPI, SDK

• Users: Up to 32

• Client Support: iVMS-4200, Hik-Connect

• Browser Support: IE10+, Chrome, Firefox

• Security: Strong password policy, watermark, MAC auth, audit logs

💾 Storage & Interfaces

• Storage: Up to 256GB microSD (optional on -F models)

• Ethernet: 1× RJ45 (10/100 Mbps)

• Reset Button: Available on -F model

⚙️ General Specs

• Power:

  • 12V DC ±25% (Max 5W)

  • PoE (IEEE 802.3af Class 3, Max 6.5W)

• Material: Metal + Plastic

• Dimensions: 170.8 × 66 × 69.1 mm

• Weight: 285g (481g with packaging)

• Operating Temp: -30°C to 60°C | ≤95% RH

• Protection: IP67

• Languages: English, Ukrainian

📜 Certifications

• EMC: CE, RCM, IC

• Safety: UL, CB, BIS

• Environmental: RoHS, WEEE, REACH

•
