•  H.265+/H.265/H.264/H.264+ video formats
• Connectable to the third-party network cameras
• Up to 16 IP cameras can be connected
• Recording at up to 8 MP resolution
• Supports live view, storage, and playback of the connected camera
  at up to 8 MP resolution
• HDMI and VGA independent outputs
• HDMI Video output at up to 4K (3840 Ã 2160) resolution
• 2 SATA interfaces connectable for recording and backup
• H.265+ compression effectively reduces the storage space and
  costs by up to 75%
• 1 self-adaptive 10/100/1000 Mbps network interface
• 8/16 independent PoE network interfaces are provided
• Centralized management of IP cameras, including configuration,
  information import/export, real-time information display, two-way
  audio, upgrade, etc.
• Connectable to smart IP cameras from Hikvision and the recording,
  playing back, and backing up of VCA alarms can be realized
• VCA detection alarm is supported
• Instant playback for assigned channel during multi-channel
  display mode
• Smart search for the selected area in the video; and smart
  playback to improve the playback efficiency
• Hik-Connect for easy network management

Specifications

Video/Audio Input

Two-way audio input:        1-ch, RCA
(2.0 Vp-p, 1kÃ)

IP video input:        16-ch

IP Video input:        Up to 8 MP
resolution

Network

Incoming bandwidth:        160Mbps

Outgoing bandwidth:        160Mbps

Video/Audio Output

HDMI Output:        1-ch,
resolution:4K (3840 Ã 2160)/30Hz,1920 Ã 1080/60Hz, 1600 Ã 1200/60Hz,
1280 Ã1024/60Hz, 1280 Ã 720/60Hz, 1024 Ã 768/60Hz.

Recording Resolution:
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Audio Output:        1-ch, RCA
(Linear, 1kÃ)

Synchronous Playback:        16-ch

VGA Output:        1-ch, resolution:
1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Decoding

Decoding format:
H.265/H.265+/H.264/H.264+/MPEG4

Capability:        1-ch @ 8 MP / 4-ch
@ 1080p

Live view / Playback:        8 MP/6
MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

Hard Disk

SATA:        2 SATA interfaces

Capacity:        Up to 6TB capacity
for each disk

Capacity:        Up to 6TB capacity
for each HDD

External Interface

Network Interface:        1RJ-45
10/100/1000Mbps self-adaptive Ethernet interface

USB Interface:        2, USB2.0

POE

Supported Standard:        AF and AT

Interface:        16 independent 10
/100 Mbps PoE Ethernet interfaces

Max. Power:        160W

General

Power Supply:        100 to 240 VAC

Power:        Ã 180W

Consumption(without hard disk and POE):
à 15W

Working Temperature:        -10 oC ~
+55 oC (+14 oF~ + 131 oF)

Working Humidity:        10 % ~ 90 %

Chassis:        1U chassis

Dimensions:        385 Ã 315 Ã 52 mm
(15.2″Ã 12.4″ Ã 2.0″)

Weight(without HDD):        Ã 2.6 kg
(5.7 lb)
